📊 Technical Parameters
| Standard Specifications |
| Overall Dimension (L*W*H) |
3650*1330*1930 mm |
| Passengers Capacity |
4 or customized |
| Max Speed |
30 km/h or Negotiable |
| Max Travelling Range |
80~120 km |
| Slope Climbing Capacity |
30% |
| Turning Radius |
4.6 m |
| Minimum Ground Clearance |
150 mm / 400 mm |
| Brake Distance |
≤5 m |
| Wheelbase |
2400 mm |
| Front/Rear Tread |
Front 900mm / Rear 1000mm |
| Weight |
620 kg |
| Certification |
CE |
⚡ Electric & Power System
| Voltage |
48V / 60V / 72V |
| Motor Power |
3.5KW / 4KW / 5KW / 7KW / 7.5KW options |
| Electric Controller |
Fully Intelligent Controller |
| Battery Type |
Lead acid or 120Ah Lithium Battery options |
| Charger |
Intelligent high-frequency car charger |
| Charging Time |
6~10 hours (discharge rate is 90%) |
| Charging Input Voltage |
220V / 110V |
| Fuel Options |
Electric or Gasoline |
🛠️ Chassis & Suspension
| Suspension System |
Front MacPherson Independent / Torsion Beam + Integral rear axle high strength steel plate |
| Brake System |
Four wheel hydraulic brake + double circuit hydraulic + parking brake + brake assist |
| Steering |
Automatic adjustment rack and pinion steering machine |
| Motion Transfer |
Continuously variable transmission |
| Drive Mode |
Rear drive |
🎨 Exterior & Interior Features
| Dashboard |
Multi-function smart display (Bluetooth, Radio, USB, MP5 player, Reversing video) |
| Lighting System |
LED combined headlights, turn signals, rear taillights, brake lights |
| Seat Material |
Imitation leather + Diamond sew seats (high resilience PU) |
| Body Material |
Steel frame + ABS injection molded engineering plastic shell |
| Wheel & Tire |
10/12/14 inch Aluminum wheels; Road or off-road tire options |
| Body Color |
Customizable (including text, stickers, and logos) |
❓ Frequently Asked Questions
1. What is the maximum range on a single charge?
Depending on the battery configuration (Lead-acid or Lithium), the travelling range typically spans between 80km and 120km.
2. How long does it take to fully charge the golf cart?
Using our intelligent high-frequency charger, a full charge usually takes between 6 to 10 hours, depending on the discharge rate.
3. Can this golf cart handle steep hills?
Yes, the vehicle is designed with a slope climbing capacity of up to 30%, making it suitable for hilly eco-resorts and golf courses.
4. Are there customization options for the color and logo?
Absolutely. The body color, stickers, and logos are fully customizable to match your brand or resort aesthetic.
5. What type of braking system is used?
The cart features a robust four-wheel hydraulic brake system, including a double circuit hydraulic brake and parking brake device for maximum safety.
6. Is the vehicle certified for international use?
Yes, our golf carts come with CE certification, ensuring they meet the required safety and environmental standards.
